مشخصات ماژول جی اس ام
| Packege: |
Module |
|---|---|
| Type: |
ماژول جي اس ام |
| Chip: |
NEO-6 |
| Size: |
35*25 میلی متر |
| Operating Voltage Range: |
3 تا 5 ولت |
ماژول جی پی اس NEO6MV2 GPS یکی از پیشرفته ترین ماژول های GPS می باشد. این ماژول از تمام پروتکل های ارتباطی پشتیبانی می کند. ماژول دارای حافظه EEPROME برای ذخیره تنظیمات است. از دیگر ویژگی های این ماژول سرعت دریافت اطلاعات و راه اندازی سریع آن می باشد.
Description
This module is compatible with APM2 and APM2.5, and the EEPROM can store all of your configuration data. Interface: RS232 TTL Power: 3-5v Baud rate Default: 9600bps No battery (this is not safe for airmail) Battery model is MS621FE, requires soldering You can download the test program directly from the ublox website (u-center version 6.31 download (requires Internet connection installation)).
Module with antenna, mini size with strong signal.
EEPROM save the configuration parameter data when power down.
With data backup.
With LED signal lights.
Compatible with various flight control modules.
Power supply: 3V-5V
Models: GY – GPS6MV2
The default baud rate: 9600
Module size: Approx. 25 mm x 35 mm / 0.98″ x 1.37″
How to get started with GY-NEO6MV2 GPS Module
The GY-NEO6MV2 GPS module series is a family of stand-alone GPS receivers featuring the high performance u-blox 6 positioning engine. These flexible and cost effective receivers offer numerous connectivity options in a miniature 16 x 12.2 x 2.4 mm package. Their compact architecture and power and memory options make GY-NEO6MV2 modules ideal for battery operated mobile devices with very strict cost and space constraints.The 50-channel u-blox 6 positioning engine boasts a Time-To-First-Fix (TTFF) of under 1 second. The dedicated acquisition engine, with 2 million correlators, is capable of massive parallel time/frequency space searches,enabling it to find satellites instantly. Innovative design and technology suppresses jamming sources and mitigates multi-path effects, giving GY-NEO6MV2 GPS receivers excellent navigation performance even in the most challenging environments.
Specifications
1.Supply Voltage:2.7 to 3.6V
2.Supply current:67 mA
3.Antenna gain:50 dB
4.Operating temperature:-40 to 85°C
5.Antenna Type:Passive and active antenna
6.Interfaces:UART,USB,SPI.
