مشخصات فنی و کاربرد

مشخصات شیلد درایور موتور آردوینو L293D



شیلد موتور درایور مدل L293D یک درایور ولتاژ بالا، جریان بالا و یکی از بهترین روش ها برای کنترل موتور DC، سرو موتور ها و استپر موتور ها می باشد. عملکرد این شیلد بر اساس تراشه L293D است و می تواند 4 موتور DC دوجهته، دو سرو موتور و دو استپر موتور را هدایت کند. این برد عمدتا با برد های آردوینو UNO و MEGA سازگار است.

هر کانال این برد می تواند تا حداکثر 600 میلی آمپر جریان دهی نماید. تراشه L293D به عنوان H-Bridge معرفی می شود. H-Bridge مداری است که در آن امکان بازگذاری ولتاژ به یک خروجی مانند موتور فراهم است.

مشخصات

دو اتصال برای سرو موتور های 5 ولت

حداکثر 4 موتور DC دو جهته با انتخاب سرعت 8 بیتی جداگانه

حداکثر دو استپر موتور با سیم پیچ تکی و دوبل

دارای 4 H-Bridge: هر پل 0.6 آمپر ( 1.2 آمپر پیک جریان)

دارای ترمینال برای اتصال آسان سیم ها

دارای دکمه ریست







https://tecsho.com/upload/imgs/1400/6/429546.PNG

L293D is a monolithic integrated, high voltage, high current, 4-channel driver.Basically this means using this chip you can drive DC motors with power supplier up to 36 Volts,and the chip can supply a maximum current of 600mA per channel. L293D chip is also known as a type of H-Bridge. The H-Bridge is typically an electrical circuit that enables a voltage to be applied across a load in either direction to an output, e.g. motor



Features

2 connections for 5V 'hobby' servos connected to the Arduino's

high-resolution dedicated timer - no jitter!



Up to 4 bi-directional DC motors with individual 8-bit speed selection



Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil,

interleaved or micro-stepping



4 H-Bridges: L293D chipset provides 0.6A per bridge (1.2A peak) with

thermal shutdown protection, 4.5V to12V



Pull down resistors keep motors disabled during power-up



Big terminal block connectors to easily hook up wires (10-22AWG) and

Power



Arduino reset button brought up top



2-pin terminal block to connect external power, for separate logic/motor

Supplies



Tested compatible with Mega, UNO& Duemilanove



Dimensions: 69mm x 53mm x 14.3mm    2.7in x 2.1in x 0.6in
